This hydraulic adaptor is designed to connect British Standard Pipe Taper (BSPT) male threads to Metric Heavy male threads at a 90° angle, allowing for directional changes in hydraulic lines while maintaining secure, high-pressure connections.
Key Features
Thread Types:
BSPT Male: Tapered thread that seals via thread interference, commonly used in British and international hydraulic systems.
Metric Heavy Male: Parallel thread with a 24° cone seat, designed for high-pressure applications per DIN 2353 standards.
Configuration: 90° elbow for compact routing in tight spaces or around machinery.
Material: Typically made from carbon steel, stainless steel, or brass, with zinc plating for corrosion resistance.
Seal Type:
BSPT side seals via thread interference.
Metric Heavy side seals via metal-to-metal contact or with an O-ring depending on the design.
Pressure Rating: Suitable for medium to high-pressure hydraulic systems (up to 6000 psi depending on size and material).
Standards: Complies with ISO 8434-1, DIN 2353, and SAE specifications.
Applications
Hydraulic systems in industrial, agricultural, and mobile equipment.
Equipment requiring conversion between British and metric thread standards.
