SAE Female Straight

A SAE Female Straight fitting typically refers to a SAE Straight Thread O-Ring Boss (ORB) female port.

• Standard: SAE J1926-1 (also known as O-Ring Boss or ORB)
• Thread Type: Straight thread (not tapered)
• Seal Type: O-ring seal between the male O-ring and the female chamfer
• Application: Common in hydraulic systems for high-pressure, leak-free connections

The female port has:

• A straight thread
• A machined surface (minimum spot face)
• A chamfer to accept the O-ring from the male fitting

Sunflex K Series
