ROBUST 4-WIRE SPIRAL CONSTRUCTION The Sunflex Total Core R4K spiral hose provides 4000 psi constant working pressure in sizes -6 to -16 designed for harsh Australian conditions where high pressure and impulse applications are required. half bend radius of traditional R12, making for easy installation this hose exceeds iso18752. Uses 2 wire K series fittings 2 wire crimp spec. • ½” Iso 18752-Cc Half Bend Radius • 4,000 PSI Constant Working Pressure • Exceeds ISO 18752-CC • 4 Wire Spiral Construction • K Series Fittings • Code Matched Hose and Fittings System • Tough Wrapped Cover Finish • The Most Flexible Hose on the Market • 4:1 Safety Factor
APPLICATION: PETROLEUM BASED HYDRAULIC FLUIDS AND OILS FITTINGS: K SERIES INNER TUBE: BLACK, OIL RESISTANT SYNTHETIC RUBBER TEMP RANGE: -40°C - 121°C REINFORCEMENT: FOUR WIRE HIGH TENSILE STEEL WIRE SPIRAL LAYERS IMPULSE CYCLES: 1,000,000 COVER: WRAPPED ABRASION, OZONE, OIL AND WEATHER RESISTANT SYNTHETIC RUBBER BRANDING: SUNFLEX GLADIATOR ISOBARIC 4K WP 280 BAR BP1120 BAR ISO 18752-CC *Please note HYD-R5K-20 is 5000 PSI Working Pressure*
