SAE 100 R2AT EN853 2SN Sunflex Total Core Magnum R2S is the industry leading R2AT hose. Although a multi-purpose hose, the Two wire extra flex design makes it the number one choice especially in mining and agriculture sectors. This hose exceeds SAE R2AT and is designed to meet the harsh Australian conditions. Uniquely patterned with a smooth cover and a distinctive royal blue finish-makes the R2S easy to identify with also an added feature of being flame proof and MSHA approved.  • Exceeds SAE Din spec  • Innovative Extra Flex design • 200,000 impulse cycles  • Easy identification with distinctive royal blue lay line • K Series fittings • Code matched hose and fitting system  • MSHA Approved • Flame Resistant • 4:1 Safety FactorÂ
APPLICATION: PETROLEUM BASED HYDRAULIC FLUIDS AND OILS  FITTINGS: K SERIES INNER TUBE: BLACK, OIL RESISTANT SYNTHETIC RUBBER  TEMP RANGE: -40°C -100°C REINFORCEMENT: TWO WIRE HIGH TENSILE STEEL WIRE BRAID  IMPULSE CYCLES: 200,000 COVER: SMOOTH, OZONE, OIL AND WEATHER RESISTANT SYNTHETIC RUBBER.        (-20,-24,-32 are wrapped cover) BRANDING: SUNFLEX 2SN DN06 DIN/EN853-SAE R2ATÂ
